Topic: Drawing not showing corectly with elevation

Hi, I have many polygons that have invisible corners when i try to display them and using elevation.

Picture attached.

Example:
[
            25.703806054376393,
            44.53245327694106
          ],
          [
            25.703804693034506,
            44.53244372481203
          ],
          [
            25.703737365876005,
            44.532447852385324
          ],
          [
            25.70369245260592,
            44.53241869185757
          ],
          [
            25.703668498482624,
            44.532403139310425
          ],
          [
            25.7036291699531,
            44.53240669801435
          ],
          [
            25.703625073949034,
            44.53237745085631
          ],
          [
            25.70361775362749,
            44.532325180666255,
            0
          ],
          [
            25.703689573505923,
            44.53232033204781,
            0
          ],
          [
            25.70374618547291,
            44.53231651009466
          ],
          [
            25.703806333133866,
            44.53235837846979
          ],
          [
            25.70393934106813,
            44.532345123402045
          ],
          [
            25.704015680368517,
            44.532195550804424
          ],
          [
            25.704125823257158,
            44.53211161773481
          ],
          [
            25.703988520644465,
            44.532105020385906
          ],
          [
            25.703939276573184,
            44.53215005664679
          ],
          [
            25.703796773422933,
            44.53214431984583
          ],
          [
            25.703802498089637,
            44.53204405852175
          ],
          [
            25.703894027998327,
            44.53204804279978
          ],
          [
            25.70389505134437,
            44.53204138052475
          ],
          [
            25.70416622616025,
            44.53205379779829
          ],
          [
            25.704166270281014,
            44.53204819735022
          ],
          [
            25.70419279220568,
            44.53204824784729
          ],
          [
            25.704210766731286,
            44.53206151765937
          ],
          [
            25.704238359939996,
            44.53208150979637
          ],
          [
            25.70424146909448,
            44.5322050647938
          ],
          [
            25.704256858466724,
            44.53222137874446
          ],
          [
            25.704209548539055,
            44.53228255509981
          ],
          [
            25.704185270298844,
            44.53233323369645
          ],
          [
            25.704174669546884,
            44.53236601818057
          ],
          [
            25.70417045245381,
            44.53240000525724
          ],
          [
            25.70417427800096,
            44.53242071012687
          ],
          [
            25.704176032096093,
            44.532430203747076
          ],
          [
            25.703971183012882,
            44.532439766150276
          ],
          [
            25.703970304069355,
            44.5324285067816
          ],
          [
            25.70390046960213,
            44.53243358118934
          ],
          [
            25.703901779117437,
            44.53244599767316
          ],
          [
            25.703806054376393,
            44.53245327694106
          ]

Thank you
